RO Control Panel MIMIC-SILVER (1000LPH)

The RO Control Panel MIMIC-SILVER (1000LPH) is an industrial-grade control panel designed for efficient water purification systems. With a sleek powder-coated white finish and compact dimensions of 80x185x210 mm, this panel is built using high-quality mild steel for durability. It operates at a frequency of 50Hz and a rated voltage range of 170V AC 280V, making it suitable for various industrial applications. Backed by a 1-year warranty, this control panel ensures reliable performance and longevity in water treatment processes.

Technical Specification

• Supply Voltage: 170V AC 280V AC
• Current Range: 0-30A
• Working Temperature: 0-50 oC
• Overall Size : 210(H) x 185(W) x 80(D)
• Phase: 1:1 (RWP 1 phase : HPP 1 Phase)

SALIENT FEATURES:

• Micro Controller & SMPS based RO DIGITAL CONTROL Panel.
• DISPLAY-Only Mimic LEDSs
• Range: 1000LPH (1:1)
• AUTO AMPEARE Settings for RWP & HPP
• AUTO / MANUAL Mode options.
• RWT & TWT Level Sensors Provision .
• HPS Provision & Monitoring.
• LPS Provision & Monitoring.
• HIGH & LOW Voltage Protections.
• RWP & HPP Overload Protections.
• UV & DOSING PUMP Connections Provision.
• FLUSHING SOLENOID VALVE Connection Provision.
• MIMIC Diagrammed with LEDs.
• Water level sensors RWT 2 nos, TWT 3 nos
