RO Control Panel LED GOLD Lite 500LPH

The RO Control Panel LED GOLD Lite 500LPH is a reliable and efficient control panel designed for industrial applications. It features a powder-coated mild steel surface finish and base material, ensuring durability and longevity. With a rated voltage of 170V AC to 280V AC and a rated current of 0-30 Ampere, this panel delivers optimal performance. The cover material is made of ABS, providing added protection. The compact dimensions of 60x125x185mm make installation easy, while the sleek white surface color adds a modern touch to any industrial setting. Backed by a 1-year warranty, this control panel is a trustworthy choice for your industrial needs.

Technical Specification

• Supply Voltage: 170V AC 280V AC
• Current Range: 0-30A
• Working Temperature: 0-50 oC
• Overall Size : 125(H) x 185(L) x 60(D)
• Phase: 1:1 (RWP 1 phase: HPP 1 Phase)

• Micro-Controller & SMPS based RO DIGITAL CONTROL Panel.
• Display-LED 4 Digit- 7 Segment
• TDS & CONDUCTIVITY Display
• Range: 500LPH (1:1)
• AUTO AMPEARE Settings for RWP & HPP
• AUTO / MANUAL Mode options.
• HIGH & LOW Voltage Protections.
• RWP & HPP Overload and Dry Run Protections.
• HPS Provision & Monitoring.
• LPS Provision & Monitoring.
• Trip Time.
• UV & Dosing Pump Connections provision.
• Raw Water Tank and Treated Water Tank Float.
• Flushing Time & Flushing Interval Time
• All settings are editable.
